TH90cn-3.5 L

Control Line

Suitable for:

90° Head machinings

Ratio
1:1

RPM up to
8000 min-1

Max axial load
1250 N

Torque
50 Nm

Weight
16 Kg

RPM dry running
4.00 min-1

Collet
ER-32 (ø 2/20 mm)

Smart Change option
Disponibile

Enter your details to receive the link to the pdf catalog of this product.

Shank available

ISO 69871
ISO 50

MAS-BT
BT 50

HSK
HSK 100, HSK 125, HSK 63, HSK 80, HSK 80-F

BBT
BBT 50

CAPTO
CAPTO C6, CAPTO C8

Output available

Collet
ER 32

Arbor output
27mm

Weldon
Ø 16mm, Ø 20mm

ISO
ISO/BT50

HSK
HSK 40

CAPTO
C3
