T90-0.5C Neo

Suitable for:
90° Head machinings
Ratio
1:1
RPM up to
10.00 min-1
Max axial load
150 N
Torque
12 Nm
kg
Weight
4 Kg
Collet
ER-11 (ø 0,5/7 mm)
Pdf catalogue download

Enter your details to receive the link to the pdf catalog of this product.

Shank available

ISO 69871
ISO 30, ISO 40, ISO 50
MAS-BT
BT 30, BT 40, BT 50
HSK
HSK 100, HSK 125, HSK 63, HSK 80, HSK 80-F
BBT
BBT 30, BBT 40, BBT 50
CAPTO
CAPTO C6, CAPTO C8
CAT
CAT 40, CAT 50

Output available

Collet
ER 11
Weldon
Ø 6mm
