TCUcn-3.5 Neo

Suitable for:
Head with adjustable angle machinings
Ratio
1:1
RPM up to
6000 min-1
Max axial load
715 N
Torque
50 Nm
kg
Weight
7 Kg
Angle
Adjustable
RPM dry running
4.00 min-1
Collet
ER-32 (ø 2/20 mm)
Pdf catalogue download

Enter your details to receive the link to the pdf catalog of this product.

Shank available

ISO 69871
ISO 50
MAS-BT
BT 50
HSK
HSK 100, HSK 125, HSK 63, HSK 80, HSK 80-F
BBT
BBT 50
CAPTO
CAPTO C6, CAPTO C8
CAT
CAT 50

Output available

Collet
ER 32
Weldon
Ø 20mm
